Terminal wire manufacturers analyze how to use the terminal block?

What is a terminal wire? The terminal cable, also called Flexible Flat Cable (FFC), can select the number and spacing of wires at will, which makes it more convenient to connect wires, greatly reduces the volume of electronic products, reduces production costs, and improves production efficiency. It is most suitable for data transmission cables between moving parts and motherboards, between PCB boards and PCB boards, and in miniaturized electrical equipment. Common specifications include 0.5mm, 0.8mm, 1.0mm, 1.25mm, 1.27mm, 1.5mm, 2.0mm, 2.54mm and other flexible cables. Terminal line function? At present, it is widely used in the connection between the printing head of various printers and the main board, the signal transmission and board connection of plotters, scanners, photocopiers, stereos, liquid crystal electrical appliances, fax machines, various DVD players and other products. In the modern electrical equipment, the terminal wire is almost everywhere? Type a: both ends are connected and the reinforcing plates are pasted on the insulating adhesive paper; Type B: the reinforcing plates are directly pasted on the insulating adhesive paper in a crossed manner; Type C: the reinforcing plates at both ends are directly pasted on the conductor; Type D: the reinforcing plates at both ends are directly pasted on the conductor in a crossed manner; Type E: the reinforcing plates at one end are pasted on the insulating adhesive paper and the reinforcing plates at the other end are directly soldered with tin; Type F: the reinforcing plates at both ends are directly pasted on the insulating adhesive paper, and the internal half is peeled off; Type G: the tin is directly soldered at both ends. How to use the wiring terminal? Materials to be prepared for the use of wiring terminals include: wiring terminals, screwdrivers, and wires. Terminals are suitable for the interconnection of a large number of wires. In the power industry, there are special terminal blocks and terminal boxes, all of which are terminals, single-layer, double-layer, current, voltage, ordinary, breakable and so on. A certain crimp area is to ensure reliable contact and to ensure that enough current can be passed. First, strip the insulation skin of the wire for 6-8 mm. 2. Then insert the exposed wire into the inside of the terminal. 3. Then tighten the top screw with a screwdriver. 4. Pull it with your hand to make sure it doesn't fall off. Five, then press the switch, see the light on, so that the wiring of the terminal is completed.

---------------------------------------------------------------------------------------------------
